The New Stäubli TF -Weaving system series for technical textiles features
modular design and allows individual configuration that meets any required
specifications. Thanks to the combination of advanced technologies like
servo-controlled shedding and parallel reed movements, weavers enjoy
unlimited design freedom to produce innovative fabrics with any required
Here are some examples.
Free selection of system components in terms of warp thread supply, shed formation,
Advantages of the technical weaving system:
weft insertion and fabric take-off. Absolute freedom in design. Gentle yarn treatment.
Reliable and durable Stäubli system components Service and support by
highly-qualified specialists worldwide.
Example system for reinforcing fabrics:
Warp thread supply: Bobbin creel and/or warp beam Shed formation:
Jacquard and/or dobby Weft selector: Multi Weft Selector 2+2 to 6+6 Weft
insertion: Single or double flexible rapier Weaving width: Standard 1.8 m /
or customisable Control: Touchscreen, integrated into the weaving system
Example system for heavy industrial textiles:
Warp thread supply: Warp beam Shed formation: Dobby (or Jacquard machine)
Weft selector: Multi Weft Selector 2+2 to 6+6 Weft insertion: Single or
double flexible rapier Weaving width: 2.5 to 10 m or more Control: Touchscreen,
integrated into the weaving system.
